ADM Losmandy-type Universal Dovetail bars

ADM Losmandy-type Universal Dovetail bars

  (12 Reviews)
✓ 2 year warranty


1x in stock shipped 1-2 working days

About this product

Model:  adm_losmandy_dovetail-1
Part Number:  DUP7M

The BEST replacement dovetail plates.

Universal Dovetail Plate for Losmandy style saddle plates. Available in 7, 11 and 15" lengths with one 4.5" long slot (two on 15" bar) for 1/4"x20 socket head cap screw or 1/4"x20 button head cap screw.

Holes are 2" apart to accommodate Parallax and other style rings.

NEW METRIC VERSION with 60mm spacing to accommodate William Optic and other metric style clam shell rings.  Ships with four 1x4x20 low profile socket head cap screws.  Please notify us if you need 6mm low profile socket head cap screws.

Manufactured from premium quality solid 5/8 inch 6061 black-anodized aluminium.

Safety stops included.

Customer reviews

Average Rating (12 Reviews):
Write a Review and share your opinions!

Rating (max 5):
Monday, 20 September 2021  |

I bought the 11inch and 15inch versions for two different scopes. Both plates are very solid and from a build perspective, inspire confidence that they’ll securely hold pretty much anything you mount on them. The provided imperial and metric screws are a bonus. The only reason for losing a star from the rating is that the finish on the 15inch plate is best described as ‘industrial’ rather than ‘refined’, with blemishes and scratches across the surface as if the anodising hasn’t been applied evenly. This doesn’t affect the usage though and I’m sure it won’t be noticed once I have a scope mounted on it.

Rating (max 5):
quality product and good value
Monday, 5 July 2021  |

I bought this to mount inverted on my SkyWatcher 150mm Esprit tube rings to take an ADM Losmandy to Vixen female adaptor. Fits perfectly and is the usual ADM quality. Good value too.

Rating (max 5):
Great service as usual
Monday, 3 May 2021  |

Great service again, very fast processing and delivery. Very solid mount plate

Rating (max 5):
Tremenda barra de milano.
Wednesday, 2 December 2020  |

Es la primera vez que compro en FLO y la experiencia a sido muy positiva, el envío a España a sido rápido, el embalaje perfecto, la barra Losmandy se ve muy rígida a pesar de su tamaño de 21", le queda como un guante a un tubo de 12" F 1600.
Seria bueno que se indicara el peso de la barra en la descripción del producto, no es una critica solo una opinión.
Gracias, saludos al equipo de FLO.

Rating (max 5):
Excellent dovetail bar
Thursday, 29 October 2020  |

Good size bar just what I needed to mount the Redcat plus accessories fast delivery great service again thanks to the team at FLO

Rating (max 5):
Good Service
Friday, 19 June 2020  |

Once again thank you for you very fast and efficient service. Good pricing too.

Rating (max 5):
ADM Quality
Sunday, 19 January 2020  |

I recently bought a new Skywatcher Esprit 100ED with the green dovetail bar, all I can say is that bar looked nice but was rubbish, I have a dual mount bar and I struggled to tighten it, the first time I mounted it I thought it was secured I turned away to get something else and heard a strange sound, looking back at my mount the scope had slipped down and was almost off when I grabbed it, since then I have made sure the mounting bar has been as tight as I can get it. After asking fo some advice from FLO I ordered the 7" version and fitted it today and the difference in quality is so noticable, I don't have to grip with all my strength to get it fixed securely now. I think I will be ordering another one to put on the top and mount my guidescope on so I can do away with the dual mounting bar

Rating (max 5):
Excellent dovetail bar
Monday, 12 August 2019  |

Really impressed by quality and accessories. Thanks to all the FLO's staff that answer my questions kindly about imperial and metric (Esprit 100 = imperial). The package takes three days to arrive to Canary Islands.

Rating (max 5):
Quality and good value
Saturday, 4 May 2019  |

I required a plate with wider 3.5inch (88.9mm) bolt spacing for the tube rings I had on my Newtonian.
The imperial plate from ADM fitted perfectly , and is supplied with both metric and imperial socket screws (I needed the 6mm ones)
Included with the plate are 2 thumbscrew end stops to prevent a loose plate from sliding out of the jaws on your mount if the clamp goes loose , always a good idea to avoid a disaster.
Impressed with the quality and they are very good value.
Great service from FLO who answered my queries about the range quickly.

Rating (max 5):
No brainer.
Monday, 18 February 2019  |

It's ADM. It's quality. That's it really.

Read all 12 customer reviews...


Please fill in the form below to ask a question.


Q1. What is the difference between the metric and imperial Losmandy universal dovetail bars?

The difference is the spacing between the outer holes ACROSS the bar. Imperial are 2" hole centres and metric are 60mm hole centres.
