Pentax ZD 43mm WP Binoculars

Pentax ZD 43mm WP Binoculars
Pentax ZD 43mm WP BinocularsPentax ZD 43mm WP BinocularsPentax ZD 43mm WP Binoculars
Pentax ZD 43mm WP BinocularsPentax ZD 43mm WP Binoculars
Choose Model:


Incoming - Shipped 4-6 working days.

Model:  pntx_zd_8x43_wp_62721
Part Number:  62721
Brand:  Pentax
Type:  Modern
Style:  Top Hinge
Magnification:  8x / 10x
Aperture:  43mm
Colour:  Black
Features:  Waterproof
Prism Type:  Roof Prism


  • ZD WP Binoculars
  • Objective Lens Caps
  • Eyepiece Lens Caps
  • Carrying Case
  • Neck Strap
  • Lens Cloth
  • Instruction Manual

Pentax Z-Series

The Z-series is the flagship of the entire Pentax range, offering premium level quality and clarity, at a price that’s within reach. The Z-series models are clearly built for critical observation. The new Full Multi-Coating and a new Enhanced Light Transmission Coating are designed to delight the most demanding users and inspire the most dedicated enthusiasts. A hydrophobic, protective coating rounds off the outdoors applications.

This series is an all-rounder! Rough and tough with an exceptional image quality, edge-to-edge sharpness, unsurpassed brightness & clarity and a resolution that will impress – especially under twilight conditions. What more could you ask for? We built this serie to weather all weather! The strong body is protected with a solid, green rubber armouring – the binocular can easily be handled when wearing gloves. To assure all-time functionality we have added a hydrophobic coating on all to-air exposed lenses – rain, fog, snow or even your own breath will no longer trouble your viewing.


  • New fully multi-coated optics
  • New enhanced light transmission coatings
  • Phase correction
  • Protective lens coating
  • Waterproof, nitrogen-filled and unique hydrophobic coating
  • Hybrid aspherical lens element
  • Magnesium alloy construction

New Fully-multi-coated optics

Fully multi-coated lenses serve the essential purpose of maximising the amount of light passing through a lens, thereby prevent flare and ghosting from interfering with your view. PENTAX applies multiple layers of coatings to every surface of every element and prism in the full Sport Optics line-up. These fully-multi-coated optics assure the maximum light transmission resulting in a clear, crisp view of the world.

New Enhanced Light Transmission Coatings

PENTAX binoculars take quality optics to the next level by applying a new, optimized film-deposition technology on lens and prism surfaces resulting in increased light transmission which creates bright images with accurate color rendition

Protective Lens Coating

All optical surfaces are delicate and must be handled with care to prevent scratching. To add to the durability of the Z- and S-series Water Proof binoculars*, PENTAX has added a protective, nano technology coating that helps deflect water, oil, dust and dirt. This allows PENTAX binoculars to withstand the harshest viewing conditions.

BaK4 prisms

Due to its outstanding refractive index, the BaK4 glass prism found in all PENTAX Sport Optics is highly acclaimed for its perfectly round exit pupil and clear, unvignetted image.

Phase Correction

The complex optical design of roof prism binoculars provide durable, compact, yet lightweight design but require a higher level of optical perfection. A phase-correction coating is applied in the full range of roof prism binoculars to maximize image viewing quality.

PENTAX Waterproofing

PENTAX waterproof products are fully sealed and purged with laboratory grade nitrogen to provide a fog proof view in the harshest weather conditions. With a JIS Class 6 rating, PENTAX waterproof binoculars can even be submerged in up to 3 feet of water.

Unique Hydrophobic Coating

Water droplets on a lens have a negative influence on the ability of light to enter the objective lens. By using a unique water repellent coating on all outer lenses we make water drops “bead” into small, deformed droplets. The deformed droplets cause less distortion and “slide” more easily off the lens. Your binocular remains fully functional even in rain, snow, fog or condensing breath.

Inner Focus Optics Design

This sophisticated optical design is critical to low-maintenance and long life guarantee. Exposure to airbourne particles and moisture is avoided, thereby ensuring that no outside influences can penetrate the housing and disrupt functionality.

Hybrid Aspherical lens elements

Edge-to-edge sharpness is a vital element to comfortable viewing. To achieve this, we utilise aspherical lens elements in our eyepieces. This is a specially shaped lens design that reduces aberration to a minimum. Hybrid-Aspherical lens elements have the additional advantage of superior functionality while being lightweight and compact.

Dielectric coating

Dielectric Coating of the prisms serves to enhance the colours of the image. Multiple layers of surface correction coatings are “vaporized” onto the surface of the prisms in a vacuum. This maximizes the quality of visible light in the color spectrum between infra-red and ultra-violet as it passes through the glass.

Nitrogen purged

Nitrogen is a chemical element and a colourless, odourless and tasteless gas. It contains very little humidity and is therefore used to “purge” binoculars and spotting scopes of the high humidity air that is part of our environment. Due to the low humidity factor, nitrogen prevents condensation from forming on the internal lenses of optical instruments during phases of rapid temperature change. Furthermore, because nitrogen is purged into the optical instrument at slightly above atmospheric pressure, dust and other miniscule particles are prevented from entering the housing.

Superb impact resistance

The body is made from magnesium, which adds toughness while keeping the binoculars light. In addition, the exterior rubber coating provides the binoculars with superb resistance to shocks and impacts.

Long eye relief design

The long eye relief offered in all PENTAX Sport Optics allows the viewer to see the entire field of view clearly and effortlessly. This is especially beneficial to eyeglass wearers, and allows viewing for extended periods of time without added eye strain.

Other Features

Helicoid four-stop eyepiece rings that permit fine adjustment for maximum viewing comfort.

Short minimum focusing distance for easy observation of nearby subjects.

Locking diopter adjuster guards against accidentally moving the diopter setting.

Product Specifications

Product Code6272162722
TypeFull-size RoofFull-size Roof
Objective Lens Diameter43 mm43 mm
Field of View at 1000m110 m105 m
Exit pupil aperture5.4 mm4.3 mm
Eye Relief22 mm17 mm
EyecupsMulti-Stop Twist-UpMulti-Stop Twist-Up
Height52 mm52 mm
Width146 mm146 mm
Depth126 mm126 mm
Weight695 g710 g
Water proofYes (JIS Class 6) Nitrogen purgedYes (JIS Class 6) Nitrogen purged
AccessoriesObjective and eyepiece caps, case, strapObjective and eyepiece caps, case, strap
Prism coatingBaK4 with High Resolution Phase Correcting coatingBaK4 with High Resolution Phase Correcting coating
Lens coatingNew fully multi-coated optics, New enhanced light transmission coatings, Protective lens coatingNew fully multi-coated optics, New enhanced light transmission coatings, Protective lens coating
Twilight Factor18.520.7
Close focus2.0 m2.0 m
Tripod AdaptorWith adapter TP-3 PENTAX Code No. 69554With adapter TP-3 PENTAX Code No. 69554

Pentax ZD 43mm WP Binoculars Questions & Answers

Please fill in the form below to ask a question.

Your Name: *
Your Email Address: *
Your Question: *
Please add the two numbers

Q1. How much do these binoculars weigh?

The Pentax ZD 8x43mm WP binoculars weigh approximately 695g / 24.52oz and the ZD 10x43 WP binoculars weight 710g / 25.04oz.
