Celestron CGX Equatorial 9.25" (925) SCT Telescope

£3,999.00
  (1 Review)
✓ 2 year warranty



Out of stock due 2-4 working days
Share

About this product

Model:  cel_cgx_925_sct_12051
Part Number:  12051-CGL

The CGX 925 includes one of Celestron’s best known Schmidt-Cassegrain Telescopes with premium StarBright XLT coated optics and the all-new state of the art CGX computerised equatorial mount.

The 9 1/4" was specifically designed for visual infinity focus when using 2" eyepieces and has an optimised baffle system to benefit astrophotography by minimising vignetting at the edge of the field of view. Its longer primary focal length and lower magnification secondary mirror contribute to a flatter field of view at the focal plane and helps to further reduce optical aberrations. It is also Fastar/Hyperstar Compatibile.

For eight years, Celestron’s workhorse CGEM mount lineup has been the German Equatorial backbone for telescopes ranging from 6 to 11 inches of aperture. Since that time, many more astro-imagers and planetarium controlled setups have emerged as backyard telescope technology has evolved. Celestron’s engineering team applied their years of experience designing German Equatorial mounts to the all-new CGX EQ, a culmination of all the advancements made to Celestron’s technologies, value, and ease-of-use.

The new CGX was designed to support your telescope for both visual and astro-imaging pursuits.  Key design goals included a lower profile EQ head for a more compact and therefore more stable setup; a better drive system; remote operation-friendly with home and limit optical sensors; easier polar alignment adjustments and better cable management. In addition, there are several mechanical and ergonomic improvements to make the mount sturdier, easier to use and transport.

CGX Intro Video




GENERAL FEATURES

  • 9.25" Schmidt-Cassegrain Optical Tube Assembly
  • Aluminum Optical Tube
  • Celestron's premium StarBright XLT coatings
  • 2350 mm focal length (f/10)
  • 25 mm eyepiece included (94x)
  • Visual back allows for use with 1.25" accessories
  • 6x30 finderscope to help accurately find objects
  • Star diagonal provides more comfortable viewing position when observing objects that are high in the sky
  • Includes dovetail rail compatible with CGE mount

CGX MOUNT FEATURES

  • All-new design. Sturdier and more rigid with quicker dampening time
  • Increased load capacity to 55 lbs.
  • Improved motors provide more torque, better slewing and tracking under heavy loads
  • Heavy Duty belt-drive system minimises backlash while providing smooth motor operation under heavy loads
  • Spring-loaded brass worm wheel and stainless steel worm gear reduce friction and provide optimum gear mesh
  • Internal cabling for worry-free remote operation. Power input and accessory ports remain stationary while the mount slews to avoid snags
  • Internal hard stops for both axes prevents cable tension and tripod strike
  • Internal optical sensors on both axes for simple and safe remote operation
  • Home sensors allow the mount to always start in the index position regardless of orientation before a power reset
  • Limit sensors automatically shut off slewing or tracking before reaching the hard stop fail safe
  • Brand new control software developed in conjunction with PlaneWave Instruments for professional level control operation and imaging
  • Software includes multi-point mount modeling for extremely precise pointing accuracy and many more additional features for remote astroimaging
  • Wider tripod stance for improved stability
  • Adjustable EQ head position to optimize center of gravity over the tripod and fully utilize the increased 3º-65º latitude range
  • Dual-fit CG-5/Vixen and CGE/Losmandy dovetail saddle

IMPROVED TRIPOD FEATURES

  • 2" steel legs with height index marks for quick leveling
  • "Jack of all trays" can hold three 1.25" eyepieces, two 2" eyepieces, your smartphone, or other accessories
  • +20º of additional tracking past the meridian on either side
  • Tripod legs can be collapsed with accessory tray installed for faster setup and transport

CGX MOUNT ERGONOMICS

  • All-new ergonomically designed dovetail clamping knobs
  • Innovative and improved polar alignment adjustment system
  • All-new ergonomic latitude adjuster for smooth and easy adjustment under full loads
  • Optional add-on polar axis finderscope - coming soon

CGX MOUNT ELECTRONICS

  • All-new NexStar+ hand control with USB port
  • Two AUX accessory ports to support wireless/WiFi alignment and operation with StarSense AutoAlign and SkyPortal WiFi Module accessories (sold separately)
  • USB 2.0 port, used to connect directly to PC with included software
  • Autoguider port
  • PPEC ready
  • Threaded 12VDC power input barrel connector
  • Internal Real Time Clock (keeps time and site information saved)

What's in the box

  • Telescope OTA
  • 6x30 Finderscope
  • 1.25" Star Diagonal
  • 25mm Eyepiece
  • CGX Equatorial Head
  • CGX Tripod
  • Accessory Tray
  • 1x 7.7kg / 17lbs Counterweight
  • NexStar+ Hand Control
  • DC Power Cable (Cigar Plug)

Specifications

Optical DesignSchmidt-Cassegrain
Aperture (mm)234.95 mm (9.25 in)
Focal Length2350 mm (93 in)
Focal Ratio10
Focal Length of Eyepiece 1 (mm)25 mm (0.98 in)
Magnification of Eyepiece 194x
Finderscope6x30
Star Diagonal1.25
Optical TubeAluminum
Highest Useful Magnification555x
Lowest Useful Magnification34x
Limiting Stellar Magnitude14.4
Resolution (Rayleigh)0.59 arc seconds
Resolution (Dawes)0.49 arc seconds
Light Gathering Power (Compared to human eye)1127x
Secondary Mirror Obstruction3.35 in (85 mm)
Secondary Mirror Obstruction by Diameter36%
Secondary Mirror Obstruction by Diameter13%
Optical CoatingsStarBright XLT
Optical Tube Length22 in (559 mm)
Optical Tube Weight20 lbs. (9.07 kg)
Dovetail CompatibilityCGE Mount
MountGerman Equatorial
Instrument load capacity55lbs
Tripod height adjustment range47.25” to 77.5” including EQ head
Tripod leg diameter2"
Latitude adjustment range3º-65º
Tripod Weight19.2 lbs
EQ Head Weight44 lbs
Max Slew Speed5º/second (4º/second is default)
Tracking RatesSidereal, Solar and Lunar
Number of Auxiliary ports (for hand control and accessories)2
Autoguide portYes
USB PortYes
SoftwareNew telescope control PC software

Customer reviews

Average Rating (1 Review):
Write a Review and share your opinions!
Rating (max 5):
Great purchase
22 October 2021  |

This was my first purchase of a 'serious' scope, and FLO were really helpful in nailing down what I wanted. The CGX mount and tripod are really solid. The mount requires a small bit of assembly, most of which is pretty straight forward. The right ascension adjustment knobs that you have to install were not mentioned but some common sense worked it out. The set up with the Nexstar is pretty simple, though I had to work out how to turn on the real time clock so the mount remembered the time. Again, not in the manual but common sense (and working through the Nexstar menu system) prevailed. The 9.25SCT is great, and easy to use, tho have not had a chance yet to test on challenging DSO yet. But I will probably order a better finder (with a right angle prism).
