Sky-Watcher Field Flattener for Esprit-100

Sky-Watcher Field Flattener for Esprit-100

£189.00
  (1 Review)
✓ 2 year warranty



2x in stock shipped 1-2 working days

Special Bundle Price - Save £34!

Buy Esprit 100 ED Pro with dedicated field flattener to save £34

Simply add both items to your basket to automatically receive the discount.

About this product

Model:  skywatcher_flattener_esprit_100_20188
Part Number:  20188

An optically-matched M48-fitting doublet field flattener for Sky-Watcher's Esprit 100 ED PRO triplet refractor.

The M48 fitting provides a large clear aperture to reduce halation and a precision thread ensures the triplet and doublet lens groups are precisely aligned on the optical axis perpendicular to the image.

When used with the field flattener the Esprit-100's imaging circle is 40 mm.

Notes

  • When fitting a DSLR camera you need only a M48 Ring to suit your Canon, Nikon or Sony DSLR camera. No spacers are required.
  • The spacing for dedicated CCD imaging cameras is 55 mm from mating surface (69.8 mm from centre of rear element).
  • The rear thread is M48. When using T-threaded accessories you will need a FLO M48-T adapter.

Customer reviews

Average Rating (1 Review):
Write a Review and share your opinions!

Rating (max 5):
Works Well with Sharpstar 94EDPH
31 October 2022  |

I purchased this flattener to use my 94EDPH at its native 517mm (or so) focal length. I had tried a couple of other flatteners that left noticeable field curvature in the corners. The Esprit flattener has only a slight distortion in the corners, and this looks to be more a factor of imager tilt vs. the flattener itself.

The only issue I faced is both the flattener and the 94EDPH focuser have female threads, so I had to purchase a custom adapter. Overall, though, I can recommend this flattener.
