Explore Scientific 62° Series Eyepieces

Explore Scientific 62° Series Eyepieces
Choose: 5.5mm (1.25Choose: 9mm (1.25Choose: 14mm (1.25Choose: 20mm (1.25
Choose: 26mm (1.25Choose: 32mm (2Choose: 40mm (2


In stock - Shipped 1-2 working days.

Model:  es_62_5-5mm
Part Number:  0219605
Brand:  Explore Scientific

Explore Scientific

For their 62° series Explore Scientific have sacrificed maximum field of view (62° is moderate these days) to deliver high performance and premium build quality at an affordable price.

Fully multicoated edge-blackened optics deliver high contrast, maximum light transmission and freedom from ghosting. The resolution is excellent and edge-to-edge field correction is impressive!

All Explore Scientific 62° eyepieces are Argon purged (the air inside is replaced with Argon, an inert gas) and sealed so the inside will never suffer from condensation. The interior optics will remain clear, bright and dust-free, year after year.

The nosepiece includes a milled safety undercut (to prevent the eyepiece slipping out of the focuser) and is threaded to accept astronomy filters.

Note to eyeglass wearers: The 20, 26, 32 & 40mm eyepieces have long eye-relief so are the best choices if you wear eyeglasses while observing.


  • High quality fully multicoated glass elements.
  • Excellent resolution and field sharpness, even with fast optics.
  • 62° apparent field of view.
  • Blackened lens edges for enhanced contrast.
  • Sealed Argon-purged body (waterproof & fog-proof).
  • Stainless steel barrel with milled safety undercut.
  • Threaded for astronomy filters.

Eyepiece Field of View Simulator

Product Specifications

Model 5.5mm 9mm 14mm 20mm 26mm 32mm 40mm
Product Code 0219605 0219609 0219614 0219620 0219626 0219632 0219640
Apparent Field of View 62º 62º 62º 62º 62º 62º 62º
Eye Relief 13mm 12mm 11mm 15mm 20mm 22mm 28mm
Barrel Size 1.25” / 31.7mm 1.25” / 31.7mm 1.25” / 31.7mm 1.25” / 31.7mm 1.25"  / 31.7mm 2” / 50.8mm 2” / 50.8mm
Height (From End of Barrel) 57mm 56mm 54mm 60mm 76mm 102mm 114mm
Weight 115g 115g 100g 145g 235g 420g 655g

Explore Scientific 62° Series Eyepieces Questions & Answers

Please fill in the form below to ask a question.

Your Name
Your Email Address
Your Question

Average Rating (2 Reviews):
Write a Review and share your opinions!

Rating (max 5):
Nice light and compact eyepiece
Monday, 28 May 2018  |

This is a nice light and compact eyepiece, unlike some other designs of similar focal lengths having apparent FOV’s which are similar or smaller, but are relatively quite bulky and heavy in comparison. At £80 it is also competitively priced
The eyepiece is comfortable to use, the eye relief is quite generous, and view quite sharp right up to the edge of the field of view. Would be nice if they also did this design in 7.5 and 4 mm focal lengths

Rating (max 5):
Just what I wanted
Thursday, 5 April 2018  |

I bought this eyepiece to use in a Lunt solar scope. I really like everything about it. Very nice small size. Good contrast across the fov and very reasonably priced. I have not had a chance to use it on the night sky yet but I am pretty sure it will perform well there to.
