About this product
Part Number: RZB-3104
Vortex made-in-Japan flagship binoculars!
The Razor Ultra HD series features Abbe-König Prisms and High Density extra-low dispersion glass lenses, all index-matched for maximum light-transmission, high colour fidelity and minimal chromatic aberration.
Supplied with a Vortex Glasspak Binocular Harness, comfort neck strap, Rainguard, tethered Objective Lens covers and of course the Vortex VIP Unlimited Lifetime Warranty.
- Abbe-König Prisms: These prisms have a longer optical path length which gives a sharper and higher resolution image.
- APO Optical System: Apochromatic optical system Index matched with HD glass lenses correct colour across the entire visual spectrum.
- Plasma Tech: Cutting edge application process provides unparalleled coating durability and performance..
- HD Lens Elements: Premium (High Density) extra-low dispersion glass delivers the ultimate in resolution and colour fidelity, resulting in Ultra High Definition images.
- XRPlus Fully Multi-Coated Lenses: Premium proprietary coatings deliver the highest level of light transmission with multiple anti-reflective coatings on all air-to-glass surfaces for maximum brightness.
- Phase Correction: Used on roof prism models only—coating enhances resolution and contrast.
- Roof Prisms: Valued for greater durability and a more compact size. Ergonomic open-hinge design.
- Magnesium Chassis: Decreases weight and increases strength.
- Waterproof: Optics are sealed with o-rings to prevent moisture, dust, and debris from getting inside the binocular.
- Fogproof: Argon gas purging guarantees superior fogproof and waterproof performance.
- Rubber Armour: Provides a secure, non-slip grip, and durable external protection.
- ArmorTek: Exterior lenses are protected by ArmorTek — an ultrahard, scratch-resistant compound that repels oil, dirt and the corrosive salts of fingerprints.
- Top Hinge: Offers superior ergonomics while decreasing total weight and bulk.
- Multi-Position Eyecups: Twist up and down to precise, intermediate settings to maximise custom fit for comfortable viewing with or without spectacles.
- Locking Diopter: Adjusts for differences in a user's eyes. Located on right eyepiece.
- Tripod Adaptable: Compatible with a tripod adapter, allowing use on a tripod or car window mount.
What's in the box
- Vortex Ultra HD 18x56 Binoculars
- Tethered Objective Lens Covers
- Vortex Glasspak Binocular Harness
- Comfort Neck Strap
- Deluxe Padded Carry Case
|Magnification ||18 x |
|Objective Lens Diameter ||56 mm |
|Eye Relief ||17 mm |
|Exit Pupil ||3.1 mm |
|Linear Field of View ||194 feet/1000 yards |
|Angular Field Of View ||3.7 degrees |
|Close Focus ||10 feet / 3.05 m |
|Interpupillary Distance ||56-76 mm |
|Height ||8.3 inches / 210 mm |
|Width ||6.1 inches / 155 mm |
|Weight ||41.6 ounces / 1180g |
Downloads / Manuals
The following manuals and downloads are available for this product:
Vortex Optics Razor Ultra HD brochure (PDF)
