Lynx Astro FTDI EQDIR USB Adapter for Sky-Watcher Mounts (see description for models)
  Zoom

Lynx Astro FTDI EQDIR USB Adapter for Sky-Watcher Mounts (see description for models)

£35.00
  (58 Reviews)
✓ 2 year warranty


:

24x in stock shipped 1-2 working days

About this product

Model:  lynxastro_eqdir_sw_rj45
Part Number:  FES-ASS-LYNX_FTDI_5V-TTL_RJ45

Updated design - longer option (5m), more flexible cable!

FTDI EQDIR USB Adapter for Sky-Watcher EQ3 PRO, EQ5 PRO, HEQ5 Syntrek & PRO, EQM-35 PRO, AZ EQ5-GT, EQ6-R PRO, AZ EQ6-GT and EQ8 Mounts.

Also suitable for use with the Orion Sirius EQ-G.

This convenient FTDI EQDIR adapter allows direct connection of Sky-Watcher EQ3 PRO, EQ5 PRO, HEQ5 Syntrek & PRO, EQM-35 PRO, AZ EQ5-GT, AZ EQ6-GT and EQ8 Mounts to your laptop.

The FTDI 232R chipset works reliably across all versions of Windows and, because each cable has a unique chipset ID, each time you unplug the adapter then plug it back into the same computer, even if on a different physical USB port, the COM port number remains the same.

We have also taken this opportunity to specify a higher quality RJ45 plug with a rubber cowl that prevents snagging and an integral 'boot' (a reinforcing sleeve) for extra strength.

And, we quality control each and every Lynx Astro cable prior to dispatch.

1, 2 or 5m cable length.

Compatible with Windows XP, 7, 8 & 10, Linux, Mac OSX 10.3 and above.

Windows users, the EQDIR adapter should install automatically but should you require drivers they can be downloaded here.

The EQMOD project consists of a suite of open source applications that bypasses the hand-controller and communicates directly with the mount's stepper motor controller.

Using EQMod article by Steve Richards

EQMOD website

EQMOD User Group

NOTE: The Skywatcher EQ5 PRO, HEQ5 PRO/Syntrek, EQM-35 PRO, AZ EQ5-GT, EQ6-R PRO, AZ EQ6-GT and EQ8 mounts all use the same Lynx Astro FTDI EQDIR adapter so if you upgrade from one to another you will not need an additional EQDIR adapter.

Customer reviews

Average Rating (58 Reviews):
Write a Review and share your opinions!

Rating (max 5):
Just what I needed.
Friday, 12 August 2022  |

It works very well with the HEQ5 Pro and EQASCOM. If necessary, the FTDI drivers must be installed.


Rating (max 5):
Lynx astro FTDI EQDIR cable.
Wednesday, 3 August 2022  |

I bought the Lynx astro FTDI EQDIR cable in order to bypass the hand controller of my Skywatcher HEQ5 Pro mount. I chose the 1M version since I plug it into a powered hub that I've attached to my mount's accessory tray. I connect the hub to my laptop with a 10M USB active repeater cable so that I can control the whole system from inside my house with NINA software. This eqdir cable is a crucial part of the train and I've read reviews of other cheaper cables that have let people down. This cable works a treat. I highly recommend it.


Rating (max 5):
Simple connection between Mac and Sky-Watcher Mount
Wednesday, 29 June 2022  |

Having seen some very complicated arrangements for connecting a Mac to a Sky-Watcher mount, it was great to find a single cable that did it all.

I had a bit of a worry that I might end up damaging the electronics in the mount but I took the plunge and plugged it in and was delighted to hear and watch the mount slew around to my commands!


Rating (max 5):
EQ6R PRO AND ASIAIR CONNECTION
Tuesday, 17 May 2022  |

WORKS PERFECTLY VERY SIMPLE TO INSTALL, A GOOD SOLID STABLE INTERFACE BETWEEN THE MOUNT AND THE ASIAIR WITHOUT THE USE OF THE HAND CONTROLLER AND IS OF VERY GOOD BUILD QUALITY A MUST HAVE WHEN WORKING REMOTE CONTROL


Rating (max 5):
Lynx Astro FTDI EQDIR USB Adapter for Sky-Watcher Mounts
Monday, 20 December 2021  |

Installed automatically running Windows 11. Works perfectly with my EQ5 Synscan mount. Using Sellarium for goto and PHD for guiding. Well packaged and promptly delivered.
My thanks to FLO.


Rating (max 5):
Works perfectly
Monday, 6 December 2021  |

Bought this to eliminate the need for a hand box whilst using my new ASIair plus, I opted for the 1Mtr version because the ASIair is mounted directly to the OTA.
Worked straight away with no issues whatsoever and as usual fast reliable delivery from FLO.


Rating (max 5):
Excellent Quality
Tuesday, 26 October 2021  |

The EQ-Mod cable by Lynx Astro is exceptionally well made and superb quality. The fit into my ASAIR Pro USB port is firm and secure. I would recommend this product.


Rating (max 5):
Lynx Astro FTDI EQDIR USB Adapter for Sky-Watcher Mounts
Sunday, 10 October 2021  |

Really pleased with this cable. The service from First Light Optics. First class


Rating (max 5):
Lynx Astro FTDI EQDIR USB Adapter for Sky-Watcher Mounts
Monday, 27 September 2021  |

I will always recommend FLO to anyone, who is into Astronomy , they have No 1 equipment , very fast service , plus well packed +++ AAAA


Rating (max 5):
Lynx Astro FTDI EQDIR USB Adapter for Sky-Watcher Mount
Tuesday, 24 August 2021  |

I bought this last week for my AZ EQ6 GT mount so I can control it from my laptop or mini pc & after downloading the drivers from here https://ftdichip.com/drivers/ it connected up & worked pretty much straight away, it seems a well made product better than the previous cable I had as the pvc outer insulation was splitting & it felt quite brittle whereas this cable is a lot more supple in comparison.


Read all 58 customer reviews...
